Package contents:- 1x Rothenberger ROMAX 4000 18 V Li-Ion Electro-hydraulic Press Machine- 1x Case with fitting insert- 1x Battery CAS Cordless Alliance System Li-HD - 18V 4.0Ah- 1x Charger CAS Cordless Alliance System 18VProduct description:This ROMAX® 4000 of the manufacturer Rothenberger is a electro-hydraulic press machine for system-dependent pressing of fittings up to Ø 110 mm with 32 - 34 kN. It is equipped with a powerful battery technology, which allows an increase in pressings per single charge. Its low weight of only 3.6 kg and balanced weight distribution reduce fatigue and enable operating in a more ergonomic and effort-saving way even during continuous use. This press machine is equally furnished with a CFT® technology which guarantees constant thrust during each press cycle. The increased service interval of 40,000 pressings/ 2 years reduces down time and increases productivity. The ROTHENBERGER battery technology brings revolution to the ROTHENBERGER battery range. Thanks to the latest battery technology and an intelligent battery management between the battery and the machine, batteries have unprecedented endurance levels. These batteries also have LED lights which indicate the charging status.Technical specifications:Voltage: 18 VUnit dimensions: 59 x 38.4 x 14.3 cmWeight incl. case: 6.73 kgREACH-compliant: YesRoHS compliant: YesCountry of origin: GermanyGross weight: 7.2 kgWorking range diameter up to (MM): 110 mmWorking range diameter from (MM): 12 mm
Package contents:
- 1x Rothenberger ROMAX 4000 Electro-Hydraulic Cordless Press Machine 18 V Li-Ion
- 1x Carry case with insert
- 1x Battery Rothenberger RO BP18/4 Li-HD - 18V/4.0 Ah ( 1000002548 )
- without charger
Product description:
The ROMAX® 4000 is an electro-hydraulic cordless press machine from Rothenberger for pressing fittings up to 110 mm in diameter and from 32 to 34 kN depending on the system. By using more powerful battery technology, a higher compression per charge is possible. Its low weight of 3.6 kg and balanced weight distribution reduce fatigue and allow ergonomic and energy-saving work over a long period of time. The CFT® technology deployed ensures the required compression force during compression. The improved service interval of 40,000 press cycles / 2 years ensures high productivity. ROTHENBERGER battery technology stands for intelligent battery management. The batteries feature LED indicators indicating the charge status.
Technical specifications:
Voltage: 18 V
pressing force: 32-34 kN
Dimensions: 59 x 38.4 x 14.3 cm
Weight: 7.51 kg
UN number: UN3481
REACH Compliance: Yes
RoHS Compliance: Yes
Country of origin: Germany
Net weight: 7.2 kg
Diameter of the working range up to (MM): 110 mm
Diameter of the working area (MM): 12 mm
Package contents:
- 1x Rothenberger ROMAX 4000 Cordless Electro-Hydraulic Press Machine 18 V Li-Ion
- 1x Carry case with insert
- without battery, without charger
Product description:
The ROMAX® 4000 is an electro-hydraulic cordless press machine from Rothenberger for pressing fittings up to 110 mm in diameter and from 32 to 34 kN depending on the system. By using more powerful battery technology, a higher compression per charge is possible. Its low weight of 3.6 kg and balanced weight distribution reduce fatigue and allow ergonomic and energy-saving work over a long period of time. The CFT® technology deployed ensures the required compression force during compression. The improved service interval of 40,000 press cycles / 2 years ensures high productivity.
Technical specifications:
Voltage: 18 V
Dimensions: 59 x 38.4 x 14.3 cm
Weight incl. case: 6.73 kg
REACH Compliance: Yes
RoHS Compliance: Yes
Country of origin: Germany
Net weight: 7.2 kg
Diameter of the working area (MM): 12 mm
Diameter of the working area up to (MM): 110 mm
Package contents:
- 1x REMS Pressing Tong Standard M 22 ( 570120 )
Product description:
The Standard M 22 pressing tongs from REMS are made of special forged and hardened stainless steel. The pressing contours of these REMS pressing tongs are system-specific and correspond to the pressing contours of the respective press machines, thus ensuring perfect, system-conform and safe pressing. These pressing tongs have a high-precision, accurately shaped and rounded pressing contour and therefore significantly lower manufacturing tolerances than the contours of cast tongs.
Technical specifications:
Diameter: 22 mm
Product weight : 1850 g
Product height : 45 mm
Product length : 150 mm
Product width: 95 mm
Country of origin: Germany
Package contents:
- 1x REMS Pressing Tong Standard M 15 ( 570110 )
Product description:
The Standard M15 pressing tongs from REMS are made of special forged and hardened stainless steel. The pressing contours of these REMS pressing tongs are system-specific and correspond to the pressing contours of the respective press machines, thus ensuring perfect, system-conform and safe pressing. These pressing tongs have a high-precision, accurately shaped and rounded pressing contour and therefore significantly lower manufacturing tolerances than the contours of cast tongs.
Technical specifications:
Diameter: 15 mm
Product weight : 1740 g
Product height : 45 mm
Product length : 145 mm
Product width: 95 mm
Country of origin: Germany
Scope of Delivery:
- 1x REMS pressing jaw pressing tongs M18 for pressing machine ACC ( 570120 )
Product Description:
The heavy-duty pressing tongs from REMS are made of forged and specially hardened special steel. The pressing contours of the REMS pressing tongs are system-specific and correspond to the pressing contours of the respective pressfitting systems. This ensures perfect, system-compliant and safe pressing. They have a high-precision machined and precisely rounded pressing contour and therefore significantly lower manufacturing tolerances than cast pressing contours.
Technical Data:
- Diameter: 18 mm
- Product weight: 1890 g
- Product height: 45 mm
- Product length: 145 mm
- Product width: 95 mm
- Country of origin: DE
- For commercial use, please observe the building regulations!For commercial use, please observe the building regulations!
Scope of Delivery:
- 1x REMS pressing jaw pressing tongs V15 for pressing machine ACC ( 570115 )
Product Description:
The heavy-duty pressing tongs from REMS are made of forged and specially hardened special steel. The pressing contours of the REMS pressing tongs are system-specific and correspond to the pressing contours of the respective pressfitting systems. This ensures perfect, system-compliant and safe pressing. They have a high-precision machined and precisely rounded pressing contour and therefore significantly lower manufacturing tolerances than cast pressing contours.
Technical Data:
- Diameter: 15 mm
- Product weight: 1740 g
- Product height: 40 mm
- Product length: 140 mm
- Product width: 100 mm
- Country of origin: DE
- For commercial use, please observe the building regulations!For commercial use, please observe the building regulations!
Scope of Delivery:
- 1x Rothenberger ROMAX AC ECO Basic 230 V crimping machine type C for mains operation ( 15705 )
- 1x transport case with matching insert
- 1x operating manual
- 1x cloth
- 1x Rothenberger crimping jaw Standard TH16 for crimping machines ROMAX 4000 ( 015322X )
- 1x Rothenberger press jaw Standard TH20 for pressing machines ROMAX 4000 ( 015324X )
- 1x Rothenberger press jaw Standard TH26 for press machines ROMAX 4000 ( 015326X )
Product Description:
This pressing machine from Rothenberger provides constant thrust thanks to Constant Force Technology. It is electro-hydraulic with 32-34 kN piston force for mains operation for system-dependent crimping of fittings with a diameter of 12 to 110 mm. The 270° rotatable Standard pressing jaw holder is compatible with many other manufacturers. It weighs approx. 4.5 kg and is therefore light and easy to handle and suitable for series crimping of fitting connections on site. After pressing and holding the start switch, the force-guided crimping process begins (force-controlled forced sequence, analogue to the specifications of leading system manufacturers). The two-switch system ( start / manual return ) ensures fatigue-free working. The device is also ergonomic thanks to the rubberised handle and balanced weight distribution. The working radius is also very wide thanks to the power cable length of 5 metres.
Technical Data:
- Voltage: 230 V
- Rated input power: 280 W
- Motor speed: 14000 min-1
- Piston force: 32 kN
- Pressing time (depending on nominal width): approx. 6-8 s
- Dimensions (LxWxH): 410 x 810 x 170 mm
- Weight: approx. 5 kg
- Working range (depending on system): Ø 12 - 110 mm
- Operating temperature: 0 - 40 °C
- Protection class: IP 20
- Protection class: II
- Operating mode: S3
- Typical weighted acceleration in the hand-arm range: up to 2.5 m/s2
- Sound pressure level (LpA): 93 dB (A) / KpA: 3 dB (A)
- Sound power level (LWA): 106 dB (A) / KWA 3 dB (A)
- For commercial use, please observe the building regulations!For commercial use, please observe the building regulations!
Package contents:
- 1x Rothenberger Press Jaw Standard M22 for pressing machine ROMAX 4000 ( 015104X )
Product description:
These press jaws from Rothenberger, whose high quality materials and workmanship have proven their worth, are suitable for pressing metal or plastic fitting systems. The use of a special hardening process, DURA LAZR TEC technology, and a partial laser hardening process allow precise and safe crimping with increased durability. This minimizes wear and tear and increases the number of pressure cycles by 100% compared to the previous model. Moreover, long-term corrosion protection increases the service life of the press jaws. Thanks to the use of high-strength special steel, these press jaws are suitable for all pressing machines with an axial thrust of 32 to 34 kN.
DURA LAZR TEC process - Partial laser hardening ensures maximum hardening in highly loaded areas. This reduces wear and tear and ensures high contour accuracy. When combined with forged, high-strength and flexible special steel, this new generation of press jaws guarantees a 100% longer service life than the previous generation. Its 3-bolt synchronization mechanism allows the pressing machine to be opened with just one finger. The precisely manufactured contour ensures optimal and secure crimping.
Technical specifications:
Product diameter: 22 mm
Product weight: 2.12 kg
Product height: 3.9 cm
Product length: 15 cm
Product width: 10.5 cm
Product country of origin: DE
Package contents:
- 1x Rothenberger Press Jaw Standard M15 for pressing machine ROMAX 4000 ( 015102X )
Product description:
These press jaws from Rothenberger, whose high quality materials and workmanship have proven their worth, are suitable for pressing metal or plastic fitting systems. The use of a special hardening process, DURA LAZR TEC technology, and a partial laser hardening process allow precise and safe crimping with increased durability. This minimizes wear and tear and increases the number of pressure cycles by 100% compared to the previous model. Moreover, long-term corrosion protection increases the service life of the press jaws. Thanks to the use of high-strength special steel, these press jaws are suitable for all pressing machines with an axial thrust of 32 to 34 kN.
DURA LAZR TEC process - Partial laser hardening ensures maximum hardening in highly loaded areas. This reduces wear and tear and ensures high contour accuracy. When combined with forged, high-strength and flexible special steel, this new generation of press jaws guarantees a 100% longer service life than the previous generation. Its 3-bolt synchronization mechanism allows the pressing machine to be opened with just one finger. The precisely manufactured contour ensures optimal and secure crimping.
Technical specifications:
Product diameter: 15 mm
Product weight: 2.04 kg
Product height: 3.9 cm
Product length: 14.5 cm
Product width: 10.5 cm
Product country of origin: DE
Scope of Delivery:
- 1x Rothenberger pressing jaw standard type SV18 ( 015213X )
Product Description:
The Rothenberger pressing jaws impress with their proven material and manufacturing quality, which is guaranteed by batch numbering and individual testing. They are suitable for system-compliant crimping of fittings made of plastic systems and metal. The 3-bolt synchronised mechanism allows the pressing jaws to be opened with one finger and ensures a high level of accuracy during pressing. The continuous bolt with no potential breaking points guarantees a long service life and a high level of safety at work. The standard pressing jaws are suitable for the ROMAX® 4000, ROMAX® 3000, ROMAX® 3000 AC and ROMAX® AC ECO.
Technical Data:
- Axial thrust: 32-34 kn
- Product weight: 1.905 kg
- Working range diameter (up to): 15 mm
- Pressing jaw for system-compliant pressing of fittings with: Ø 15 mm (metal)
- Product height: 3.9 cm
- For commercial use, please observe the building regulations!For commercial use, please observe the building regulations!
Package contents:
- 1x Rothenberger ROMAX 4000 Cordless Electro-Hydraulic Press Machine 18 V Li-Ion
- 1x Carry case with insert
- without battery, without charger
Product description:
The ROMAX® 4000 is an electro-hydraulic cordless press machine from Rothenberger for pressing fittings up to 110 mm in diameter and from 32 to 34 kN depending on the system. By using more powerful battery technology, a higher compression per charge is possible. Its low weight of 3.6 kg and balanced weight distribution reduce fatigue and allow ergonomic and energy-saving work over a long period of time. The CFT® technology deployed ensures the required compression force during compression. The improved service interval of 40,000 press cycles / 2 years ensures high productivity.
Technical specifications:
Voltage: 18 V
Dimensions: 59 x 38.4 x 14.3 cm
Weight incl. case: 6.73 kg
REACH Compliance: Yes
RoHS Compliance: Yes
Country of origin: Germany
Net weight: 7.2 kg
Diameter of the working area (MM): 12 mm
Diameter of the working area up to (MM): 110 mm
