AMF AMF push rod clamp no. 6841 size 3 ( 4000833518 )
Fri, 09/19/2025
Scope of Delivery: - Push rod clamp no. 6841 size 3 - Supplied with hardened and tempered, galvanised tightening screw no. 6880 Product Description: with small angled foot - push and pull clamp - with long push rod guide - the clamp can be attached to sheet metal walls without an angled foot or screwed into fixture bodies with a thread on the end face Technical Data: - A: 12mm - D: 6.5mm - M max.: 42.5mm - M min.: 29.5mm - L2: 22mm - M2: M20x1.5mm - L1: 140mm - H1: 108mm - F1: 2.5kN - Total height: 110mm - B max: 69mm - Bore Ø: 6.5 mm - F2: 2.5kN - B min.: 37mm - P: 30mm - K: 13mm - E: 30mm - H: 25mm - N: 60mm - Total length: 140mmFor commercial use, please observe the building regulations!
CHF 48.21
-
AMF AMF push rod clamp no. 6841 size 5 ( 4000833519 )
Fri, 09/19/2025
Scope of Delivery: - Push rod clamp no. 6841 size 5 - Supplied with hardened and tempered, galvanised tightening screw no. 6880 Product Description: with small angled foot - push and pull clamp - with long push rod guide - the clamp can be attached to sheet metal walls without an angled foot or screwed into fixture bodies with a thread on the end face Technical Data: - A: 16mm - D: 8.5mm - M max: 46mm - M min: 29mm - L2: 25mm - M2: M24x1.5mm - L1: 171.5mm - H1: 129.5mm - F1: 4.5kN - Total height: 126mm - B max: 81.5mm - Bore Ø: 8.5mm - F2: 4.5kN - B min.: 41.5mm - P: 35mm - K: 15.5mm - E: 50mm - H: 30mm - N: 65mm - Total length: 171.5mmFor commercial use, please observe the building regulations!
CHF 71.13
-
AMF AMF push rod clamp no. 6842 size 3 ( 4123680130 )
Fri, 09/19/2025
Scope of Delivery: - Push rod clamp no. 6842 size 3 Product Description: heavy - push and pull clamp - with long push rod guide - base body made of malleable cast iron, painted - lever parts and push rod made of tempered steel, galvanised and passivated - rivets made of stainless steel, which run in case-hardened bearing bushes for size 3 - bearing points greased - handle made of red, oil-resistant plastic - for sizes 3 and 5: ergonomic, oil-resistant handle with large hand rest and soft component - complete with tempered, galvanised pressure screw Technical Data: - A: 12mm - C: 41mm - D: 6.5mm - M max: 44mm - M min: 36mm - L1: 139mm - H1: 116mm - F1: 4kN - Total height: 115mm - B max: 72mm - Bore Ø: 6.5 mm - F2: 4kN - B min.: 40mm - P: 95mm - Feature: heavy, push/pull clamp - K: 28mm - E: 30mm - H: 30mm - N: 60mm - Total length: 140mmFor commercial use, please observe the building regulations!
CHF 58.68
-
AMF AMF push rod clamp no. 6842 size 5 ( 4123680150 )
Fri, 09/19/2025
Scope of Delivery: - Push rod clamp no. 6842 size 5 Product Description: heavy - push and pull clamp - with long push rod guide - base body made of malleable cast iron, painted - lever parts and push rod made of tempered steel, galvanised and passivated - rivets made of stainless steel, which run in case-hardened bearing bushes for size 3 - bearing points greased - handle made of red, oil-resistant plastic - for sizes 3 and 5: ergonomic, oil-resistant handle with large hand rest and soft component - complete with tempered, galvanised pressure screw Technical Data: - A: 16mm - C: 41mm - D: 8.5mm - M max: 50mm - M min: 41mm - L1: 174mm - H1: 137.5mm - F1: 10kN - Total height: 134mm - B max: 98mm - Bore Ø: 8.5mm - F2: 10kN - B min.: 58mm - P: 121mm - Feature: heavy, push/pull clamp - K: 45mm - E: 50mm - H: 38mm - N: 71mm - Total length: 172mmFor commercial use, please observe the building regulations!
CHF 82.79
-
AMF AMF push rod clamp no. 6844 size 2 ( 4123665200 )
Fri, 09/19/2025
Scope of Delivery: - Push rod clamp no. 6844 size 2 - Supplied with hardened and tempered, galvanised tightening screw no. 6880 Product Description: short design - push and pull clamp - with long push rod guide - the clamp can be attached to sheet metal walls or screwed into fixture bodies with threads on the face - stainless steel version available on request. Detailed CAD dimensions available on data carriers on request. Technical Data: - A: 10mm - L2: 13mm - M2: M16x1.5mm - HW min.: 17mm - L1: 68,5mm - HW max.: 25mm - H1: 73mm - F1: 1kN - Total height: 76mm - F2: 1kN - B: 36mm - L3: 68mm - E: 15mm - M: M6mm - N: 30,5mmFor commercial use, please observe the building regulations!
CHF 40.10
-
AMF AMF push rod clamp no. 6844 size 3 ( 4123665300 )
Fri, 09/19/2025
Scope of Delivery: - Push rod clamp no. 6844 size 3 - Supplied with hardened and tempered, galvanised tightening screw no. 6880 Product Description: short design - push and pull clamp - with long push rod guide - the clamp can be attached to sheet metal walls or screwed into fixture bodies with threads on the face - stainless steel version available on request. Detailed CAD dimensions available on data carriers on request. Technical Data: - A: 12mm - L2: 16mm - M2: M20x1.5mm - HW min.: 22mm - L1: 108mm - HW max.: 35mm - H1: 123mm - F1: 2.5kN - Total height: 128mm - F2: 2.5kN - B: 57mm - L3: 115mm - E: 25mm - M: M8mm - N: 33mmFor commercial use, please observe the building regulations!
CHF 45.63
-
AMF AMF push rod clamp no. 6844 size 5 ( 4123665500 )
Fri, 09/19/2025
Scope of Delivery: - Push rod clamp no. 6844 size 5 - Supplied with hardened and tempered, galvanised tightening screw no. 6880 Product Description: short design - push and pull clamp - with long push rod guide - the clamp can be attached to sheet metal walls or screwed into fixture bodies with threads on the face - stainless steel version available on request. Detailed CAD dimensions available on data carriers on request. Technical Data: - A: 16mm - L2: 24mm - M2: M24x1.5mm - HW min.: 30mm - L1: 175mm - HW max.: 50mm - H1: 149mm - F1: 4kN - Total height: 148mm - F2: 4kN - B: 92mm - L3: 139mm - E: 45mm - M: M12mm - N: 49mmFor commercial use, please observe the building regulations!
CHF 68.40
-
AMF AMF push rod clamp no. 6845 size 3 ( 4000604385 )
Fri, 09/19/2025
Scope of Delivery: - Push rod clamp no. 6845 size 3 Product Description: Pressure clamp - (push rod and hand lever counter-rotating) - with long push rod guide - base body made of malleable cast iron, painted - lever parts and push rod made of tempered steel, galvanised and passivated - rivets made of stainless steel running in case-hardened bearing bushes - bearing points greased - ergonomic, oil-resistant handle with large hand rest and soft component - Advantage: - Low overall height in clamping position Technical Data: - F1: 4kN - Property: Compression clampFor commercial use, please observe the building regulations!
CHF 58.68
-
AMF AMF protective cap no. 6893 ( 4000604720 ) M10
Scope of Delivery: - 1x AMF protective cap M10 Product Description: made of oil-resistant neoprene to protect sensitive workpieces - hardness 70 Shore A - suitable for pressure screws no. 6880, 6885, 6890 and 6892 - for fitting onto hexagon head screw ISO 272 Technical Data: - D: 22mm - H1: 8.5mm - SW: 16mm - H: 17,5mm - D1: 15mm - Size: M10 - Brand: AMFFor commercial use, please observe the building regulations!For commercial use, please observe the building regulations!
-
AMF AMF protective cap no. 6893 ( 4000604724 ) M4
Fri, 09/19/2025
Scope of Delivery: - 1x AMF protective cap M4 Product Description: made of oil-resistant neoprene to protect sensitive workpieces - hardness 70 Shore A - suitable for pressure screws no. 6880, 6885, 6890 and 6892 - for fitting onto hexagon head screw ISO 272 Technical Data: - D: 11mm - H1: 4.2mm - SW: 7mm - H: 8,5mm - D1: 7mm - Size: M4 - Brand: AMFFor commercial use, please observe the building regulations!For commercial use, please observe the building regulations!
CHF 17.58
-
AMF AMF protective cap no. 6893 ( 4000604725 ) M5
Fri, 09/19/2025
Scope of Delivery: - 1x AMF protective cap M5 Product Description: made of oil-resistant neoprene to protect sensitive workpieces - hardness 70 Shore A - suitable for pressure screws no. 6880, 6885, 6890 and 6892 - for fitting onto hexagon head screw ISO 272 Technical Data: - D: 12.5mm - H1: 5mm - SW: 8mm - H: 10mm - D1: 8mm - Size: M5 - Brand: AMFFor commercial use, please observe the building regulations!For commercial use, please observe the building regulations!
CHF 17.97
-
AMF AMF protective cap no. 6893 ( 4000604726 ) M6
Fri, 09/19/2025
Scope of Delivery: - 1x AMF protective cap M6 Product Description: made of oil-resistant neoprene to protect sensitive workpieces - hardness 70 Shore A - suitable for pressure screws no. 6880, 6885, 6890 and 6892 - for fitting onto hexagon head screw ISO 272 Technical Data: - D: 15mm - H1: 6mm - SW: 10mm - H: 12mm - D1: 10mm - Size: M6 - Brand: AMFFor commercial use, please observe the building regulations!For commercial use, please observe the building regulations!
CHF 18.46
