AMF AMF washer DIN 6340 ( 4000833437 ) for M10 screws
Fri, 09/19/2025
Scope of Delivery: - 1x AMF washer for M10 screws Product Description: tempered (350 + 80 HV30) - dimensions according to DIN, but punched and pressed flat Technical Data: - S: 4mm - D2: 28mm - D1: 10,5mm - for screws: M10 - Brand: AMF - Bore Ø: 10.5 mmFor commercial use, please observe the building regulations!For commercial use, please observe the building regulations!
CHF 7.85
-
AMF AMF washer DIN 6340 ( 4000833439 ) for screws M14
Fri, 09/19/2025
Scope of Delivery: - 1x AMF washer for M14 screws Product Description: tempered (350 + 80 HV30) - dimensions according to DIN, but punched and pressed flat Technical Data: - S: 5mm - D2: 40mm - D1: 15mm - for screws: M14 - Brand: AMF - Bore Ø: 15 mmFor commercial use, please observe the building regulations!For commercial use, please observe the building regulations!
CHF 8.16
-
AMF AMF Parallel pad set no. 6344SP ( 4000603656 ) Contents 8 pairs Size 25-39 Length 110 mm
Scope of Delivery: - 1x AMF parallel underlay set Contents 8 pairs Size 25-39 - Size 25 - 39, content 1 pair each: 0.3x25 / 0.3x27 / 0.3x29 / 0.3x31 / 0.3x33 / 0.3x35 / 0.3x37 / 0.3x39 mm (WxH) Product Description: wave-shaped - in wooden box - material thickness 0.3 mm - precision ground - spring steel hardened and tempered - height graduation 2 mm - pair tolerance tp in height IT 5 - nominal dimension tolerance in height ±0.004 mm - other dimensions according to DIN ISO 2768m Technical Data: - Content: 8 pairs - Size: 25-39 - Length: 110 mm - Width: 0.3 mm - Brand: AMF - Design: wavy - Height: 25-39 mmFor commercial use, please observe the building regulations!For commercial use, please observe the building regulations!
-
AMF AMF Parallel underlay set no. 6348P ( 4123321021 ) Contents 24 pairs Size 125 Length 125 mm
Fri, 09/19/2025
Scope of Delivery: - 1x AMF parallel underlay set Contents 24 pairs Size 125 - Size 125, contents 1 pair each: 8x11 / 8x16 / 8x21 / 8x26 / 8x31 / 8x36 / 10x13 / 10x18 / 10x23 / 10x28 / 10x33 / 10x38 / 12x15 / 12x20 / 12x25 / 12x30 / 12x35 / 12x40 / 14x17 / 14x22 / 14x27 / 14x32 / 14x37 / 14x42 mm (WxH) Product Description: nan Technical Data: - Content: 24 pairs - Size: 125 mm - Length: 125 mm - Width: 8-14 mm - Brand: AMF - Design: Precision - Height: 11-42 mmFor commercial use, please observe the building regulations!For commercial use, please observe the building regulations!
CHF 470.42
-
AMF AMF screw-in support no. 6400 ( 4000833114 ) size 70 height 50 - 70 mm
Fri, 09/19/2025
Scope of Delivery: - 1x AMF screw jack size 70 Product Description: with flat support - spindle: trapezoidal thread, self-locking, with end stop - tempered steel, painted - thanks to the robust design, the screw jacks with infinitely variable adjustability function safely and precisely even under the heaviest loads Technical Data: - Max. load capacity: 100kN - Centre hole Ø: 12mm - H max.: 70mm - D2: 50mm - TR: 30 x 4mm - H min.: 50mm - D1: 50mm - Size: 70 - Brand: AMF - Feature: with flat support - Height: 50 - 70 mm - Model: No. 6400For commercial use, please observe the building regulations!For commercial use, please observe the building regulations!
CHF 42.79
-
AMF AMF T-slot nut (DIN 508) factory standard ( 4000603172 ) T-slot 28 mm M16
Fri, 09/19/2025
Scope of Delivery: - 1x AMF T-slot nut T-slot 28 mm M16 Product Description: hardened and tempered - strength class 10 - full load capacity of the nut for T-slot can only be achieved if the screw connection is made over the entire thread length Technical Data: - A: 27.7mm - D: M16 - K: 18mm - E: 44mm - H: 36mm - Thread: M16 - T-slot: 28 mm - Brand: AMFFor commercial use, please observe the building regulations!For commercial use, please observe the building regulations!
CHF 23.96
-
AMF AMF slot nut no. 6322A ( 4000833235 ) Nominal dimension of the slot 14 / 20 mm
Fri, 09/19/2025
Scope of Delivery: - 1x AMF slot nut Nominal dimension of the slot 14 / 20 mm Product Description: for fixed mounting - C15 case-hardened Technical Data: - Nominal dimension of the groove for machine: 14mm - Nominal dimension of the groove for device: 20mm - Recommended use: for fixed mounting - L: 25mm - H: 10mm - for screws DIN 84: M6 x 16 mm - Nominal dimension of the groove: 14 / 20 mm - Length: 25 mm - Brand: AMFFor commercial use, please observe the building regulations!For commercial use, please observe the building regulations!
CHF 36.81
-
AMF AMF Fork clamp DIN 6315B ( 4000603053 ) Slot width 26 mm for clamping screw M24
Scope of Delivery: - 1x AMF fork clamp slot width 26 mm Product Description: bevelled - tempered steel - lacquered Technical Data: - Width: 66 mm - A: 50mm - B1: 26mm - B2: 66mm - Weight: 7600g - L: 500mm - B4: 10mm - Thickness: 50mm - B3: 20mm - for clamping screw: M24 - Length: 500 mm - Brand: AMF - Slot width: 26 mm - Design: bevelledFor commercial use, please observe the building regulations!For commercial use, please observe the building regulations!
-
AMF AMF screw-in support no. 6400 ( 4000833115 ) size 100 height 70 - 100 mm
Fri, 09/19/2025
Scope of Delivery: - 1x AMF screw jack size 100 Product Description: with flat support - spindle: trapezoidal thread, self-locking, with end stop - tempered steel, painted - thanks to the robust design, the screw jacks with infinitely variable adjustability function safely and precisely even under the heaviest loads Technical Data: - Max. load capacity: 100kN - Centre hole Ø: 12mm - H max.: 100mm - D2: 50mm - TR: 30 x 4mm - H min.: 70mm - D1: 50mm - Size: 100 - Brand: AMF - Feature: with flat support - Height: 70 - 100 mm - Model: No. 6400For commercial use, please observe the building regulations!For commercial use, please observe the building regulations!
CHF 47.74
-
AMF AMF Parallel underlay set no. 6348P ( 4123321022 ) Contents 24 pairs Size 150 Length 150 mm
Fri, 09/19/2025
Scope of Delivery: - 1x AMF parallel underlay set Contents 24 pairs Size 150 - Size 150, contents 1 pair each: 8x11 / 8x16 / 8x21 / 8x26 / 8x31 / 8x36 / 10x13 / 10x18 / 10x23 / 10x28 / 10x33 / 10x38 / 12x15 / 12x20 / 12x25 / 12x30 / 12x35 / 12x40 / 14x17 / 14x22 / 14x27 / 14x32 / 14x37 / 14x42 mm (WxH) Product Description: nan Technical Data: - Content: 24 pairs - Size: 150 mm - Length: 150 mm - Width: 8-14 mm - Brand: AMF - Design: Precision - Height: 11-42 mmFor commercial use, please observe the building regulations!For commercial use, please observe the building regulations!
CHF 509.37
-
AMF AMF push rod clamp no. 6840 ( 4000604395 ) size 5
Scope of Delivery: - 1x AMF push rod clamp size 5 - Supplied with hardened and tempered, galvanised tightening screw no. 6880 Product Description: without angled foot - push and pull clamp - (push rod and hand lever synchronised) - long push rod guide with fastening thread and nut Technical Data: - A: 16mm - L2: 25mm - M2: M24x1.5mm - HW min.: 30mm - L1: 171.5mm - HW max.: 50mm - H1: 99mm - F1: 4.5kN - B max.: 66.5mm - F2: 4.5kN - B min.: 26.5mm - L3: 158mm - E: 50mm - N: 34.5mm - Size: 5 - Pressure screw: M12 x 50 - Stroke: 40 mm - Length clamped: 171.5 mm - Height clamped: 99 mm - Holding force F2: 4.5 kN - Holding force F1: 4.5 kN - Brand: AMFFor commercial use, please observe the building regulations!For commercial use, please observe the building regulations!
-
KANCA Kanca protective jaw ( 4000830505 ) for jaw width 180 mm
Fri, 09/19/2025
Scope of Delivery: - 1x KANCA protective jaw for jaw width 180 mm Product Description: for gentle clamping of sensitive workpieces - 2 pcs. required Technical Data: - Material: plastic - for jaw width: 180 mm - Brand: KANCAFor commercial use, please observe the building regulations!For commercial use, please observe the building regulations!
CHF 64.99
