Scope of Delivery:
- 1x STAHLWILLE angle/torque spanner 1 - 10 Nm
- incl. 2 calibration certificates in accordance with DIN EN ISO 6789-2:2017 (triggering and indicating), 1 angle of rotation calibration certificate and operating instructions, SensoMaster software - USB cable - batteries (4 x type AAA), replacement batteries see item no. 4000 901 810 Supplied in a sturdy plastic case
Product Description:
with holder for insertion tools - electromechanical - indicating and releasing - 4 measuring modes: torque, angle of rotation, torque with control variable angle of rotation, angle of rotation with control variable torque - Nm, ft-lb, in-lb as units of measurement - for controlled clockwise and anti-clockwise tightening - torque and angle of rotation visible simultaneously - Art.No. 8000 332 362, 8000 332 365 and 8000 332 367 Measurement independent of the point of application of force - with QuickRelease safety lock - immediately ready for operation again after release - adjustable via keypad - large, high-resolution, colour graphic display - signal lights on the side - can be documented with SensoMaster software - up to 200 tightening operations programmable in max. 25 schedules with different tolerance limits - data storage up to 2.500 screwdriving operations incl. date & time stamp - ergonomic 2-component handle (resistant to oils, greases, fuels, brake fluids and Skydrol) - automatic calibration with the perfectControl® calibration and adjustment device - accuracy angle of rotation: display deviation: ±1° ±1 digit up to 100°, >100° at least 1% ± 1 digit, display resolution: 0.1°, accuracy torque: display deviation: ± 2 %, ± 1 digit, display resolution: = 60 Nm: 0.01 Nm
Technical Data:
- Sk: 17.5mm
- Lk: 188mm
- Packaging: plastic box
- Certificate: yes
- subject to inspection: yes
- Width mm (b): 28mm
- Weight: 370g
- Weight with box: 795g
- Size: 1
- Height mm (h): 23mm
- LF: 188mm
- SF: 17,5mm
- Model: 714/1
- Working range Nm: 1 - 10 Nm
- Working range lbf.in lbf.ft.: 0.7 - 7.5 ft.lb
- Holder mm: 9 x 12 mm
- Length: 226 mm
- Brand: STAHLWILLENote on the disposal of batteries and rechargeable batteries As we sell batteries and rechargeable batteries or devices containing batteries and rechargeable batteries, we are obliged under the German Battery Act (BattG) to draw your attention to the following: The symbol of the crossed-out dustbin on batteries or accumulators means that they must not be disposed of with household waste after use. If batteries or accumulators contain mercury, cadmium or lead, you will find the respective chemical symbol (Hg, Cd or Pb) below the symbol of the crossed-out dustbin. Every user of batteries or accumulators is legally obliged to return old batteries and accumulators. You can do this free of charge at a retail outlet or other collection point in your area. You can obtain the addresses of suitable collection centres in your area from your city or local authority. For batteries that contain more than 0.0005 per cent mercury by mass, more than 0.002 per cent cadmium by mass or more than 0.004 per cent lead by mass, the chemical designations of the pollutant used can be found under the waste bin symbol. The chemical designations have the following meaning: Pb: Battery contains lead Cd: Battery contains cadmium Hg: Battery contains mercuryFor commercial use, please observe the building regulations!For commercial use, please observe the building regulations!
