Scope of Delivery:
- Leakage current clamp CM 9-1 Measuring range 0.010 mA - 60 A AC
- Delivery incl. bag, test leads, batteries (2 x type AAA), spare batteries see art. no. 4000 901 810
Product Description:
4-digit illuminated LCD display (6,000 dots) - Measurement of leakage, residual. protective conductor and load currents in electrical systems, devices and machines - measurement without disconnection under normal operating conditions - ideal for preventive maintenance and troubleshooting (protection against property damage and personal injury, power failures, etc.) - reliable and simple detection of insulation faults (e.g. defective cables, loose terminals, dirt, moisture, etc.) frequency characteristics in accordance with EN 61557-16 for testing electrical devices in accordance with VDE 0701-0702 - LPF low-pass filter (40 - 70 Hz) for suppressing high-frequency interference signals - frequency range for railway and industrial applications: 15 Hz - 1 kHz (fg) - Defined protection against external magnetic fields in accordance with EN 61557-13, class 2 ≤ 30 A/m - Automatic range selection - Peak value (PEAK), measured value memory (HOLD) - Zero adjustment (ZERO) - Clamp opening max. 23 mm - Measuring category CAT IV 300 V, CAT III 600 V - Measuring ranges: Alternating current (0.010 mA - 60 A), highest resolution of 1 µA in the 6 mA measuring range, voltage (0.01 V - 600 V AC/DC), resistance (0.1 Ω - 600 kΩ), continuity test
Technical Data:
- Width: 76mm
- Length: 210mm
- Height: 34mm
- Display: LCDNote on the disposal of batteries and rechargeable batteries
- As we sell batteries and rechargeable batteries or devices containing batteries and rechargeable batteries, we are obliged under the Battery Act (BattG) to inform you of the following: The symbol of the crossed-out dustbin on batteries or accumulators means that they must not be disposed of with household waste after use. If batteries or accumulators contain mercury, cadmium or lead, you will find the respective chemical symbol (Hg, Cd or Pb) below the symbol of the crossed-out dustbin. Every user of batteries or accumulators is legally obliged to return old batteries and accumulators. You can do this free of charge at a retail outlet or other collection point in your area. You can obtain the addresses of suitable collection centres in your area from your city or local authority. For batteries that contain more than 0.0005 per cent mercury by mass, more than 0.002 per cent cadmium by mass or more than 0.004 per cent lead by mass, the chemical designations of the pollutant used can be found under the waste bin symbol. The chemical designations have the following meaning: Pb: Battery contains lead Cd: Battery contains cadmium Hg: Battery contains mercuryFor commercial use, please observe the building regulations!
