AMF AMF Clamping arm DIN 6316 for T-slot 16 + 18 mm ( 4000833059 )
Scope of Delivery: - Clamping arm DIN 6316 for T-slot 16 + 18 mm Product Description: single offset - tempered steel - painted Technical Data: - Width: 50 mm - Length: 125 mm - A: 25mm - B1: 18mm - C: 20mm - B2: 50mm - E2: 40mm - E1: 51,5mm - Weight: 1049g - L: 125mm - Thickness: 25mm - Slot width: 18mm - B3: 25mmFor commercial use, please observe the building regulations!
-
AMF AMF Spanneisen DIN 6316 für T-Nut 16 + 18 mm ( 4000833060 )
Lieferumfang:Spanneisen DIN 6316 für T-Nut 16 + 18 mmProduktbeschreibung:einfach gekröpft · Vergütungsstahl · lackiert Technische Daten: Breite: 50 mm Länge: 160 mm A: 25mm B1: 18mm C: 20mm B2: 50mm E2: 50mm E1: 51,5mm Gewicht: 1366g L: 160mm Stärke: 25 mm Schlitzbreite: 18 mm B3: 25mm
-
AMF AMF clamp no. 6314V for T-slot 12 + 14 mm ( 4000603022 )
Sat, 09/20/2025
Scope of Delivery: - Clamping arm no. 6314V for T-slot 12 + 14 mm Product Description: bevelled - with adjustable support screw - tempered steel, painted Note: Dimension h = depends on the groove depth according to DIN 650 and the screw-in length of the nut. Clamping irons without clamping screw are available in sizes 12 and 14, 16 and 18 as well as 20 and 22 mm. Technical Data: - Width: 40 mm - Length: 100 mm - A: 20mm - B1: 14mm - B2: 40mm - E2: 40mm - D: M12 - E1: 21mm - Weight: 635g - L: 100mm - Thickness: 20mm - LS: 94mm - Slot width: 14 mm - H: 10 - 92mmFor commercial use, please observe the building regulations!
CHF 34.73
-
AMF AMF clamp no. 6314V for T-slot 12 mm ( 4000833072 )
Scope of Delivery: - Clamping arm no. 6314V for T-slot 12 mm Product Description: bevelled - with adjustable support and clamping screw - tempered steel, painted Note: Dimension h = depends on the groove depth according to DIN 650 and the screw-in length of the nut. Clamping irons without clamping screw are available in sizes 12 and 14, 16 and 18 as well as 20 and 22 mm. Technical Data: - Width: 40 mm - Length: 100 mm - A: 20mm - B1: 14mm - B2: 40mm - E2: 40mm - D: M12 - E1: 21mm - Weight: 700g - L: 100mm - Thickness: 20mm - LS: 49mm - Slot width: 14 mm - H: 10 - 40mmFor commercial use, please observe the building regulations!
-
AMF AMF clamp no. 6314V for T-slot 14 mm ( 4000833073 )
Sat, 09/20/2025
Scope of Delivery: - Clamping arm no. 6314V for T-slot 14 mm Product Description: bevelled - with adjustable support and clamping screw - tempered steel, painted Note: Dimension h = depends on the groove depth according to DIN 650 and the screw-in length of the nut. Clamping irons without clamping screw are available in sizes 12 and 14, 16 and 18 as well as 20 and 22 mm. Technical Data: - Width: 40 mm - Length: 100 mm - A: 20mm - B1: 14mm - B2: 40mm - E2: 40mm - D: M12 - E1: 21mm - Weight: 720g - L: 100mm - Thickness: 20mm - LS: 49mm - Slot width: 14 mm - H: 10 - 38mmFor commercial use, please observe the building regulations!
CHF 37.94
-
AMF AMF clamping claw no. 6313K size 13 for T-slot 12 + 14 mm ( 4000603000 )
Sat, 09/20/2025
Scope of Delivery: - 1x AMF clamping claw no. 6313K size 13 for T-slot 12 + 14 mm Product Description: short - with U-piece - infinitely adjustable - hardened and tempered - galvanised and blue passivated Technical Data: - Length: 88 mm - B1: 13mm - B2: 38mm - E2: 28mm - E1: 23mm - Weight: 260g - H1: 0-35mm - H2: 30-55mm - L: 88mm - K: 14mmFor commercial use, please observe the building regulations!
CHF 33.86
-
AMF AMF Spannpratze Nr. 6313K Größe 18 für T-Nut 16 + 18 mm ( 4000603003 )
Lieferumfang:1x AMF Spannpratze Nr. 6313K Größe 18 für T-Nut 16 + 18 mmProduktbeschreibung: kurz · mit U-Stück · stufenlos verstellbar · vergütet · verzinkt und blau passiviert Weitere technische Daten: Länge: 130 mm B1: 18mm B2: 56mm E2: 38mm E1: 29mm Gewicht: 809g H1: 0-55mm H2: 42-84mm L: 130mm K: 18mm
-
AMF AMF clamping claw no. 6321 for T-slot 14 mm ( 4000833066 )
Sat, 09/20/2025
Scope of Delivery: - 1x AMF clamping claw no. 6321 for T-slot 14 mm Product Description: infinitely adjustable - steel - forged and tempered - galvanised - Application: The infinitely adjustable clamping claw quickly bridges different clamping heights without an additional base and requires little space on the machine table. It is designed for maximum loads and is particularly suitable for clamping cutting and punching tools. Note: With screws for T-slots DIN 787, length 160 mm, a maximum clamping height of 75 mm can be achieved with clamping claw sizes 12 and 14. Technical Data: - Length: 140 mm - B1: 17mm - B2: 50mm - E2: 55mm - E1: 30mm - Weight: 1080g - L: 140mm - H: 0-50mm - Application: The stepless clamping claw quickly bridges different clamping heights without an additional base and requires little space on the machine table. It is designed for maximum loads and is particularly suitable for clamping cutting and punching tools.For commercial use, please observe the building regulations!
CHF 56.70
-
AMF AMF clamping claw no. 6321 for T-slot 16 mm ( 4000833067 )
Sat, 09/20/2025
Scope of Delivery: - 1x AMF clamping claw no. 6321 for T-slot 16 mm Product Description: infinitely adjustable - steel - forged and tempered - galvanised - Application: The infinitely adjustable clamping claw quickly bridges different clamping heights without an additional base and requires little space on the machine table. It is designed for maximum loads and is particularly suitable for clamping cutting and punching tools. Note: With screws for T-slots DIN 787, length 160 mm, a maximum clamping height of 75 mm can be achieved with clamping claw sizes 12 and 14. Technical Data: - Length: 140 mm - B1: 17mm - B2: 50mm - E2: 55mm - E1: 30mm - Weight: 1270g - L: 140mm - H: 0-75mm - Application: The stepless clamping claw quickly bridges different clamping heights without additional support and requires little space on the machine table. It is designed for maximum loads and is particularly suitable for clamping cutting and punching tools.For commercial use, please observe the building regulations!
CHF 60.30
-
AMF AMF clamping claw no. 6321 for T-slot 18 mm ( 4000833068 )
Sat, 09/20/2025
Scope of Delivery: - 1x AMF clamping claw no. 6321 for T-slot 18 mm Product Description: infinitely adjustable - steel - forged and tempered - galvanised - Application: The infinitely adjustable clamping claw quickly bridges different clamping heights without an additional base and requires little space on the machine table. It is designed for maximum loads and is particularly suitable for clamping cutting and punching tools. Note: With screws for T-slots DIN 787, length 160 mm, a maximum clamping height of 75 mm can be achieved with clamping claw sizes 12 and 14. Technical Data: - Length: 140 mm - B1: 17mm - B2: 50mm - E2: 55mm - E1: 30mm - Weight: 1280g - L: 140mm - H: 0-75mm - Application: The stepless clamping claw quickly bridges different clamping heights without additional support and requires little space on the machine table. It is designed for maximum loads and is particularly suitable for clamping cutting and punching tools.For commercial use, please observe the building regulations!
CHF 60.30
-
AMF AMF clamping claw no. 6321 for T-slot 20 mm ( 4000833069 )
Scope of Delivery: - 1x AMF clamping claw no. 6321 for T-slot 20 mm Product Description: infinitely adjustable - steel - forged and tempered - galvanised - Application: The infinitely adjustable clamping claw quickly bridges different clamping heights without an additional base and requires little space on the machine table. It is designed for maximum loads and is particularly suitable for clamping cutting and punching tools. Note: With screws for T-slots DIN 787, length 160 mm, a maximum clamping height of 75 mm can be achieved with clamping claw sizes 12 and 14. Technical Data: - Length: 175 mm - B1: 21mm - B2: 60mm - E2: 70mm - E1: 40mm - Weight: 2300g - L: 175mm - H: 0-85mm - Application: The stepless clamping claw quickly bridges different clamping heights without additional support and requires little space on the machine table. It is designed for maximum loads and is particularly suitable for clamping cutting and punching tools.For commercial use, please observe the building regulations!
-
AMF AMF clamping screw set no. 6520 ( 4000833381 ) T-slot 12 mm M12 38-piece
Scope of Delivery: - 1x AMF clamping screw set T-slot 12 mm M12 - T-slot bolts DIN 787 Stud bolts DIN 6379 Hexagon nuts DIN 6330 B Extension nuts no. 6334 Spherical washers + conical sockets DIN 6319 C + G Washers DIN 6340 Product Description: for T-slots - all parts hardened and tempered - strength 8 or 10 - complete in wooden box with hinged lid Technical Data: - Contents: 38 pieces - T-slot: 12 mm - Thread: M12 - Brand: AMFFor commercial use, please observe the building regulations!For commercial use, please observe the building regulations!
